The IGLib base library for development of numerical, technical and business applications.
|
Interface for real functions. More...
Public Member Functions | |
double | Value (double x) |
Returns the value of this function at the specified parameter. More... | |
double | Derivative (double x) |
Returns the first derivative of this function at the specified parameter. More... | |
double | Derivative (double x, int order) |
Returns the derivative of the given order of this function at the specified parameter. More... | |
bool | HigherDerivativeDefined (int order) |
Tells whether the derivative of the given order is defined for this function (by implementation, not mathematically) More... | |
double | SecondDerivative (double x) |
Returns the second derivative of the given order of this function at the specified arameter. More... | |
double | Integral (double x) |
Returns integral from 0 to x of the function. Throws an exception if the integral is not defined. More... | |
double | Inverse (double y) |
Returns Inverse of the current function applied to function argument. Throws an exception if the inverse function is not defined. More... | |
void | Tabulate (double from, double to, int numPoints) |
Tabulates the current function and its first and second derivatives (when available) on the specified interval, in the specified number of points. More... | |
void | Tabulate (double from, double to, int numPoints, bool printDerivatives) |
Tabulates the current function and its first and eventually second derivatives (when available) on the specified interval, in the specified number of points. More... | |
void | Tabulate (double from, double to, int numPoints, bool printDerivatives, bool printSecondDerivatives) |
Tabulates the current function and eventually its first and second derivatives (when available) on the specified interval, in the specified number of points. More... | |
double | NumericalIntegral (double from, double to, int numintervals) |
Calculates numerical integral of this function. Simpson's formula is usually used. More... | |
double | NumericalDerivative (double x, double stepsize) |
Calculates numerical derivative of this function. Central difference formula is used. More... | |
double | NumericalSecondDerivative (double x, double stepsize) |
Calculates numerical second order derivative of this function. Central difference formula is used. More... | |
Properties | |
string | Name [get] |
Returns a short name of the function. More... | |
string | Description [get] |
Returns a short description of the function. More... | |
bool | ValueDefined [get] |
Tells whether value of the function is defined by implementation. More... | |
bool | DerivativeDefined [get] |
Tells whether the first derivative is defined for this function (by implementation, not mathematically) More... | |
bool | SecondDerivativeDefined [get] |
Tells whether the second derivative is defined for this function (by implementation, not mathematically) More... | |
bool | IntegralDefined [get] |
Tells whether analytical itegral of the function is defined or not. More... | |
bool | InverseDefined [get] |
Tells whether analytical inverse function is defined or not. More... | |
Interface for real functions.
$A Igor xx;
double IG.Num.IRealFunction.Value | ( | double | x | ) |
Returns the value of this function at the specified parameter.
Implemented in IG.Gr.PlotterZedGraph.ExampleSineFunctionForLissajous, IG.Gr3d.VtkPlotBase.ExampleFunctionTorusKnot, IG.Gr3d.VtkPlotBase.ExampleSineFunctionForLissajous, IG.Num.RealFunction, and IG.Num.RealFunctionBase.
Referenced by IG.Num.GridGenerator1dBase.CalculateGridUnitFactors(), IG.Lib.RealFunctionLoader.Example(), and IG.Num.Field< TElement >.MapCoordinates1dPlain().
double IG.Num.IRealFunction.Derivative | ( | double | x | ) |
Returns the first derivative of this function at the specified parameter.
Implemented in IG.Num.RealFunction, and IG.Num.RealFunctionBase.
Referenced by IG.Lib.RealFunctionLoader.Example().
double IG.Num.IRealFunction.Derivative | ( | double | x, |
int | order | ||
) |
Returns the derivative of the given order of this function at the specified parameter.
Implemented in IG.Num.RealFunction, IG.Num.Func.Constant, IG.Num.Func.Identity, and IG.Num.RealFunctionBase.
bool IG.Num.IRealFunction.HigherDerivativeDefined | ( | int | order | ) |
Tells whether the derivative of the given order is defined for this function (by implementation, not mathematically)
Implemented in IG.Num.Func.Cubic, IG.Num.FunctionPolynomial, IG.Num.Func.WeightPol7, IG.Num.RealFunction, IG.Num.Func.WeightPol5, IG.Num.Func.WeightPol4, IG.Num.Func.Quadratic, IG.Num.Func.Constant, IG.Num.Func.WeightPol3, IG.Num.Func.Identity, IG.Num.Func.WeightReciprocalPower, IG.Num.Func.PenaltyPower, IG.Num.Func.ReciprocalPower, IG.Num.RealFunctionBase, IG.Num.Func.Linear, IG.Lib.LoadableRealFunctionBase, IG.Num.Func.WeightGauss, and IG.Num.Func.Exp.
double IG.Num.IRealFunction.SecondDerivative | ( | double | x | ) |
Returns the second derivative of the given order of this function at the specified arameter.
Implemented in IG.Num.RealFunction, and IG.Num.RealFunctionBase.
double IG.Num.IRealFunction.Integral | ( | double | x | ) |
Returns integral from 0 to x of the function. Throws an exception if the integral is not defined.
x | Upper bound of the integral. |
Implemented in IG.Num.RealFunction, and IG.Num.RealFunctionBase.
double IG.Num.IRealFunction.Inverse | ( | double | y | ) |
Returns Inverse of the current function applied to function argument. Throws an exception if the inverse function is not defined.
Implemented in IG.Num.RealFunction, and IG.Num.RealFunctionBase.
void IG.Num.IRealFunction.Tabulate | ( | double | from, |
double | to, | ||
int | numPoints | ||
) |
Tabulates the current function and its first and second derivatives (when available) on the specified interval, in the specified number of points.
from | Left interval bound. |
to | Right interval bound. |
numPoints | Number of points in which the function is calculated. |
Implemented in IG.Num.RealFunctionBase.
void IG.Num.IRealFunction.Tabulate | ( | double | from, |
double | to, | ||
int | numPoints, | ||
bool | printDerivatives | ||
) |
Tabulates the current function and its first and eventually second derivatives (when available) on the specified interval, in the specified number of points.
from | Left interval bound. |
to | Right interval bound. |
numPoints | Number of points in which the function is calculated. |
printDerivatives | Whether to print the derivatives. |
Implemented in IG.Num.RealFunctionBase.
void IG.Num.IRealFunction.Tabulate | ( | double | from, |
double | to, | ||
int | numPoints, | ||
bool | printDerivatives, | ||
bool | printSecondDerivatives | ||
) |
Tabulates the current function and eventually its first and second derivatives (when available) on the specified interval, in the specified number of points.
from | Left interval bound. |
to | Right interval bound. |
numPoints | Number of points in which the function is calculated. |
printDerivatives | Whether to print the derivatives. |
printSecondDerivatives | Whether to print the second derivatives. |
Implemented in IG.Num.RealFunctionBase.
double IG.Num.IRealFunction.NumericalIntegral | ( | double | from, |
double | to, | ||
int | numintervals | ||
) |
Calculates numerical integral of this function. Simpson's formula is usually used.
from | Lower integral limit. |
to | Upper integral limit. |
numintervals | Number of subintervals (1 less thatn the number of evaluation points) |
Implemented in IG.Num.RealFunctionBase.
double IG.Num.IRealFunction.NumericalDerivative | ( | double | x, |
double | stepsize | ||
) |
Calculates numerical derivative of this function. Central difference formula is used.
x | Point at which derivative is calculated. |
stepsize | Step size. |
Implemented in IG.Num.RealFunctionBase.
double IG.Num.IRealFunction.NumericalSecondDerivative | ( | double | x, |
double | stepsize | ||
) |
Calculates numerical second order derivative of this function. Central difference formula is used.
x | Point at which second order derivative is calculated. |
stepsize | Step size. |
Implemented in IG.Num.RealFunctionBase.
|
get |
Returns a short name of the function.
Referenced by IG.Num.GridGenerator1dBase.CalculateGridUnitFactors().
|
get |
Returns a short description of the function.
|
get |
Tells whether value of the function is defined by implementation.
Referenced by IG.Num.GridGenerator1dBase.CalculateGridUnitFactors(), and IG.Lib.RealFunctionLoader.Example().
|
get |
Tells whether the first derivative is defined for this function (by implementation, not mathematically)
Referenced by IG.Lib.RealFunctionLoader.Example().
|
get |
Tells whether the second derivative is defined for this function (by implementation, not mathematically)
|
get |
Tells whether analytical itegral of the function is defined or not.
|
get |
Tells whether analytical inverse function is defined or not.
